Back to FLAME RETARDANT HEAT TRANSFER REFLECTIVE TAPE

XM-8104/12 – Liso-O HT – Reflective tape

Flame Resistant – Orange Heat Transfer Reflective tape – PU+Polyester

  1. Heat Transfer

  2. Glass beads: Ra>100

  3. FR PU+Polyester

  4. Roll size: 5cm x 100m

  5. 30x wash at 60°C (140°F)

SKU: XM-8104/12 Category: Tags: ,

Reflective tape XM-8104/12 in Orange colour with Flame Resistant properties. Designed for Heat Transfer application on FR-workwear and Firefighters clothing.

New 8000-series of tapes is to be tested & certified in SATRA(UK) lab in the nearest months. Yet, we have already finished our in-house testing and all the tapes performed very well. Initial value of XM-8104/12 Ra=100. After 50 washes at 60oС, the tape has met the requirements of Flammability test (ISO 15025, Edge ignition) and Retro-reflectivity test (Ra=448).

It is planned that XM-8104/12 would pass EN 469 & EN 20471 certification after 50 wash cycles at 60oC.

Reflective tapes of 8000-serie are high-tech material, that is why we urge you before the first use to check the suitability of the tapes on a sample FR-clothing. It is also useful to make trial washes of the fr-clothing with applied tape.

To correctly apply XM-8000 series HT reflective tape to FR-clothing, please read the instructions and follow them step by step. Also, please bear in mind that XMS™ Heat transfer tape is fixed better on woven fabrics, than on knits.




Weight0.0272 kg
Article

XM-8104/12 (LISO-O HT)

Composition

Colour & Width

Orange 5 cm

Reflectivity, R

HS code (NCM code)

5907009000

Volume, CBM (1 box)

0.0365 CBM

1 roll length

100 meters

1 roll weight

2.7 kgs

Number of rolls in 1 box

10 rolls

Weight netto of 1 box

27 kgs

Weight brutto of 1 box

27.6 kgs

Total meters in 1 box

1000 meters

Washing

,


This reflective tape has been tested and certified after the following number of wash cycles:


30x Wash (Domestic) at 60°C
XM-8104/12 Care Instructions

Wash: Machine Wash Warm, 40°C

Bleach: Do not bleach

Dry: Tumble Dry Low, 55°C

Dry-clean: Do not dry clean

Iron: Iron at low temperature, 110°C
Keep in cool dry place, with no direct sunlight

FR-clothing or HighVis clothing with this reflective tapes should be washed and cleaned by the above recommendations.


howtoapplyxm 6015 new

How to apply heat transfer FR reflective tape XM-6015

This silver heat transfer reflective tape is flame resistant. It is made for High Visibility of people working at the risk of fire. Certified to EN469 and EN20471, XM-6015 FR-tape resists 50 wash cycles at 60°C. You can use it for fr-clothing, where stitching of reflective tape is not an option. You don’t need to have professional equipment to apply this reflective tape on your work clothes. All you need (Read more...)


  •
